CDD-562AL/564A/L Multi-Channel Demodulator Revision 0
Telnet and CLI Operation MN-CDD562AL564AL
9–44
IP Bulk #2
EVENTLOG
PARAM
o Date Time
Build Date and Time
o Name
CEFD FW#
o Rev
Revision #
o Len
Size of each FW file
NOTE:
• There is a single Boot FW file.
• The Bulk file contains all of the FW files for the unit. Two slots are available.
• The FPGA files are subsets of the Bulk FW.
EVENTLOG
• Shows the date/time that the EVENTLOG file was last updated.
PARAM
• Shows the date/time that the PARAM1 file was last updated/saved. This also shows what user
interface was used to update/save the PARAM file last time.
o From CLI – shows ‘console’
o From Web – shows ‘http’
o From Telnet – shows Telnet user login name
o From SNMP – shows ‘snmp’
Press any key to return to the previous CLI menu screen.
