OM20 Universal Outdoor Modem Web Browser/Remote Protocol
MN-OM20– Revision 5 6–58
Features Menu
Figure 6-29. Features Menu
The Web Browser menu allows viewing of actively enabled features. Each feature displays a
series of symbols that describe feature status. The following symbols indicate:
Installed
No hardware available.
Requires hardware for
upgrade.
Feature is in Demo Mode and
will expire.
Key Code Required
Call customer service.
Feature is enabled for
customer use, but the OM20
hardware required has not
been detected or has failed.
Features upgrades can also be implemented through the Web Browser interface.
