IMPORTANT NOTE: The information contained in this document supersedes all previously published information regarding this product. Product specifica

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM viii IF YOU ARE EMPLOYEE OF A COMPANY AND/OR ARE USING THIS SOFTWARE AT

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM ix maintenance or any upgrade feed that is required. Any upgrades obtaine

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM x 8. Export Restrictions THIS EULA IS EXPRESSLY MADE SUBJECT TO ANY LAWS,

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM xi Customer Support Contact the Comtech EF Data Customer Support Departme

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM xii Notes:

1–1 Chapter 1. INTRODUCTION 1.1 Overview The Comtech EF Data (CEFD) CiLink (CSAT/XSAT iPAQ Link) software accessory supports the monito

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Introduction MN/CiLink.IOM 1–2 1.2 Using Memory Expansion Cards The HP iPAQ Pocket PC support

2–1 Chapter 2. SETUP 2.1 Getting Started The items shown in Figure 2-1 depict what is minimally required to use this installation and operations manu

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Setup MN/CiLink.IOM 2–2 Figure 2-2. Comtech EF Data’s Family of Low to High Power CSAT-5060

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Setup MN/CiLink.IOM 2–3 IMPORTANTThroughout this manual, ‘transceiver’ and ‘XCVR’ are used int

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Setup MN/CiLink.IOM 2–4 2.4 Opening a CiLink Session

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Setup MN/CiLink.IOM 2–5 Figure 2-7 on the preceding page illustrates the sequence of actions f

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Setup MN/CiLink.IOM 2–6 Notes:

3–1 Chapter 3. OPERATIONS 3.1 Establishing the Communications Link Before proceeding further, the transceiver installation must be powered on. Note t

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–2 3.2 Setting the Transceiver Address If the transceiver’s addre

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–3 ICON FUNCTION Tap the [Get Data] icon to refresh the active s

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–4 3.3.2 Main Menu Æ Configuration There are five configuration mod

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–5 3.3.2.1 Main Menu Æ Configuration Æ System Type There are two mo

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–6 3.3.2.2 Main Menu Æ Configuration Æ Signal Path The currently se

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–7 3.3.2.3 Main Menu Æ Configuration Æ LNA (Low Noise Amplifier) Th

Copyright © Comtech EF Data, 2009. All rights reserved. Printed in the USA. Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.333.2

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–8 3.3.2.4 Main Menu Æ Configuration Æ Miscellaneous The currently

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–9 3.3.2.5 Main Menu Æ Configuration Æ Redundancy Controller • For

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–10 3.3.2.5.1 Redundancy Controller Error States If the user attemp

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–11 3.3.4 Main Menu Æ Current Fault Status The currently selected t

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–12 3.3.5 Main Menu Æ Stored Events / Alarms The currently selected

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–13 3.3.6 Main Menu Æ Set Time / Date & CID The currently selec

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Operations MN/CiLink.IOM 3–14 Notes:

METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281 0.01094

2114 WEST 7TH STREET TEMPE ARIZONA 85281 USA 480 • 333 • 2200 PHONE 480 • 333 • 2161 FAX

This page is intentionally blank.

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Table of Contents MN/CiLink.IOM iii Table of Contents TABLE OF CONTENTS ...

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Table of Contents MN/CiLink.IOM iv 2.4 Opening a CiLink Session ...

vPreface About this Manual This manual provides installation and operation information for the Comtech EF Data (CEFD) CiLink software accessory use

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM vi Conventions and References Cautions and Warnings WARNING indicates

CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2 Preface MN/CiLink.IOM vii Installation Guidelines Regarding Power Line Quality IMPORTANT Comtec
