SDM-2020 Satellite Demodulator Revision 4

Front Panel Operation MN/SDM2020D.IOM

6–23

6.1.5.5 Function Select: Configuration: Recall

CONFIGURATION XX

RECALL

The Configuration Recall (XX = 1 through 10) menu allows the user to recall a

previously saved configuration setup. Upon entry, select memory location 1 through 10

by pressing [↑] or [↓].

Press <ENTER> to execute the recall.

6.1.6 Function Select: Monitor

FUNCTION SELECT

MONITOR

Press <ENTER> to review or edit the following sub-menus.

Function Select: Monitor: Raw BER

RAW BER

2.4 E-3

Displays the current BER or No Data (if carrier is not locked).

Range: <m.m E-e to >m.m E-e.

Notes:

1. Low limit based on performance.

2. High limit based on data/code rate

Press [←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement

the selected kbps. Press <ENTER> to execute the change.
