SDM-2020 Satellite Demodulator Revision 4
Specification MN/SDM2020D.IOM
5–9
5.3 Data Rates
Table 5-4. Unframed (187) Mode
Code Rate
Minimum
Data Rate
(bps)
Maximum
Data Rate
(bps)
Minimum
Symbol Rate
(sym/s)
Maximum
Symbol Rate
(sym/s)
Remarks
QPSK 1/2 1,375,000 34,375,000 1,500,000 37,500,000
QPSK 2/3 1,833,333 45,000,000 1,500,000 36,818,181
QPSK 3/4 2,062,500 45,000,000 1,500,000 32,727,272
QPSK 5/6 2,291,666 45,000,000 1,500,000 29,454,545
QPSK 7/8 2,406,250 45,000,000 1,500,000 28,051,948
8-PSK 2/3 2,750,000 68,750,000 1,500,000 37,500,000
8-PSK 5/6 3,437,500 85,937,500 1,500,000 37,500,000
8-PSK 8/9 3,666,666 91,666,666 1,500,000 37,500,000
16-QAM 3/4 4,125,000 91,666,666 1,500,000 33,333,333
16-QAM 7/8 4,812,500 91,666,666 1,500,000 28,571,428
Table 5-5. 188 Mode
Code Rate
Minimum
Data Rate
(bps)
Maximum
Data Rate
(bps)
Minimum
Symbol Rate
(sym/s)
Maximum
Symbol Rate
(sym/s)
Remarks
QPSK 1/2 1,382,353 34,558,823 1,500,000 37,500,000
QPSK 2/3 1,843,137 45,000,000 1,500,000 36,622,340
QPSK 3/4 2,073,529 45,000,000 1,500,000 32,553,191
QPSK 5/6 2,303,921 45,000,000 1,500,000 29,297,872
QPSK 7/8 2,419,117 45,000,000 1,500,000 27,902,735
8-PSK 2/3 2,764,705 69,117,647 1,500,000 37,500,000
8-PSK 5/6 3,455,882 86,397,059 1,500,000 37,500,000
8-PSK 8/9 3,686,274 92,156,862 1,500,000 37,500,000
16-QAM 3/4 4,147,058 92,156,862 1,500,000 33,333,333
16-QAM 7/8 4,838,235 92,156,862 1,500,000 28,571,428
Table 5-6. 204 Mode
Code Rate
Minimum
Data Rate
(bps)
Maximum
Data Rate
(bps)
Minimum
Symbol Rate
(sym/s)
Maximum
Symbol Rate
(sym/s)
Remarks
QPSK 1/2 1,500,000 37,500,000 1,500,000 37,500,000
QPSK 2/3 2,000,000 45,000,000 1,500,000 33,750,000
QPSK 3/4 2,250,000 45,000,000 1,500,000 30,000,000
QPSK 5/6 2,500,000 45,000,000 1,500,000 27,000,000
QPSK 7/8 2,625,000 45,000,000 1,500,000 25,714,285
8-PSK 2/3 3,000,000 75,000,000 1,500,000 37,500,000
8-PSK 5/6 3,750,000 93,750,000 1,500,000 37,500,000
8-PSK 8/9 4,000,000 100,000,000 1,500,000 37,500,000
16-QAM 3/4 4,500,000 100,000,000 1,500,000 33,333,333
16-QAM 7/8 5,250,000 100,000,000 1,500,000 28,571,428
