SDM-2020 Satellite Demodulator Revision 4
LVDS Data Interface MN/SDM2020D.IOM
8–6
applications, the polarity of signals may be inverted from the Functional Select:
Configuration: Interface menu.
Table 8-2. DVB Interface Connector Pinout, J3 RX OUT
Pin # Signal Function/Name Type Comment
1 Clock A O Demod
2 System GND I/GND Demod,
LVDS Interface - N/A, jumper on GND only
3 Data 7 A(MSB/Serial) O Demod
4 Data 6 A O Demod
5 Data 5 A O Demod
6 Data 4 A O Demod
7 Data 3 A O Demod
8 Data 2 A O Demod
9 Data 1 A O Demod
10 Data 0 A O Demod
11 DVALID A O Demod
12 SYNC A O Demod
13 Cable Shield O Demod
14 Clock B O Demod
15 System GND
I/GND Demod,
LVDS Interface - N/A, jumper on GND only
16 Data 7 B (MSB/Serial) O Demod
17 Data 6 B O Demod
18 Data 5 B O Demod
19 Data 4 B O Demod
20 Data 3 B O Demod
21 Data 2 B O Demod
22 Data 1 B O Demod
23 Data 0 B O Demod
24 DVALID B O Demod
25 SYNC B O Demod
8.1.4.1.2 Connector Pinouts, J4
Note: Table 8-3 is included for reference only. The provided data pertains to the
SDM-2020 Satellite Modulator.
The connector is sub-miniature 25-pin D female, with threaded jack nuts (refer to
Table 8-3 for connector pinouts). All signals for this connector are inputs to the
Modulator, except the signal pair on pins 2 and 15 (for an exception, see Figure 8-1, for
jumper settings).
When used as a serial data port, Data 7 (pins 3 and 16) are the active data pins. For DVB
parallel operation, Data 7 through Data 8 are used.
Signal levels are as defined in TIA/EIA-644. Per TM1449, the differential sense of all
signal pairs is a logic “1” when “A” is positive with respect to “B”. This is the normal
selection in the Functional Select: Configuration: Interface menu. For DBS
