OM20 Universal Outdoor Modem Technical Specifications
MN-OM20– Revision 5 8–14
8.13.8 BER Performance (8PSK Turbo)
1E-9
1E-8
1E-7
1E-6
1E-5
1E-4
1E-3
1E-2
1E-1
0 1 2 3 4 5 6 7 8 9 10 11 12
Eb/No in dB
BER
Turbo Decoder
Specification
Turbo 3/4
Typical
Performance
8PSK Uncoded Theory
Specification
Turbo 7/8
Figure 8-8. OM20 8PSK BER Performance (Turbo)
