Digital Satellite Terminal System Revision 1

Low Noise Block Converter MN/DST.IOM

4–7

4.4 LNB Installation

4.4.1 LNB Tooling

Refer to Figure 4-1.

1/2-inch

Box Wrench (or adjustable)

5/16-inch

Box Wrench (or adjustable)

7/16-inch

Box Wrench (or adjustable)

7/64-inch

SAE Allen

Metric Allen Wrench

Screw Driver

Phillips

4.4.2 C-Band

Table 4-3. Selection of LNB to OMT

LNB Part No. LNB

Description

Comment

RF/LNB3.6-4.2FE

LNB, EXT REF Type F Connector.

RF/LNB3.6-4.2F03

LNB, 3 ppm INT REF Type F Connector.

4.4.3 Ku-Band

Table 4-4. Selection of LNB to OMT

LNB Part No. LNB

Description

Comment

RF/LNB-10.9-11.7

RF/LNB-11.7-12.2

RF/LNB-12.2-12.7

LNB, EXT REF Type N Connector. For Spares

or use with SDM-300L2 and

other modems with Type N RF

receive connector.

RF/LNB10.9-11.7FE

RF/LNB11.7-12.2FE

RF/LNB12.2-12.7FE

LNB, EXT REF Type F Connector. Use with

SDM-300L3 / CiM-300L and

other modems with Type F RF

receove connector.

RF/LNB10.9-11.7F03

RF/LNB11.7-12.2F03

RF/LNB12.2-12.7F03

LNB, 3 ppm INT REF Type F Connector. Use with

SDM-300L3 / CiM-300L and

other modems with Type F RF

receive connectors.
