Digital Satellite Terminal System Revision 2

Installation MN/DST.IOM

2–3

2.2.2 Mounting Kit

Table 2-2. Optional: Mounting Kit, KT/6228-1 (IDU to Rack)

QTY Part Number Description

FP/6138-1 Bracket, Rear Support

4 HW/10-32x1/2RK Bolt, #10 Rack

2 HW/10-32X1/4 SHC Screw, Socket 10-32 x 1/4inch

2.3 Installation

2.3.1 IDU Installation

Tools Required:

Screw Driver

Phillips

5/32-inch

SAE Allen Wrench

Refer to Figure 2-1. Use mounting kit KT/6228-1.

1. Install the IDU rear support brackets as follows:

a. Install provided rear support bracket onto the mounting rail of the rack.

Fasten with provided bracket bolts.

b. Fasten the provided #10 socket head screws to the rear-side mounting holes

on either side of the chassis modem. Mount the modem into the equipment

rack ensuring that the socket heads engage into the slots of the rear support

brackets.

Note: It may be necessary to adjust the location of the rear mounting rails of

the rack.

c. Refer to Chapter 3 prior to connecting.
