Part Number MN/LNAS.IOM Revision 0 IMPORTANT NOTE: The information contained in this document supersedes all previously published infor

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM vi Electrical Safety The LNA Low Noise Amplifier Series has been shown to comply with

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM viiThe LNA is designed for connection to a power system that has separate ground, lin

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM viiiEMC (Electromagnetic Compatibility) In accordance with European Directive 89/336/

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM ixWarranty Policy This Comtech EF Data product is warranted against defects in materi

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM x Notes: ___________________________________________________________________________

1–1 Chapter 1. INTRODUCTION 1.1 Introduction The Comtech EF Data (CEFD) Low-Noise Amplifier (LNA) series (Figure 1-1) includes LNAs, available in C

LNA Low-Noise Amplifier Series Revision 0 Introduction MN/LNAS.IOM 1–2 1.2 TECHNOLOGY The amplifiers incorporate both HEMT (High Electron Mobilit

2–1 Chapter 2. INSTALLATION 2.1 Unpacking Inspect shipping containers for damage. If shipping containers are damaged, keep them until the contents o

LNA Low Noise Amplifier Series Revision 0 Installation MN/LNAS.IOM 2–2 2.2 Mounting No special tools are required. 2.3 LNA Connector Pinouts LNA

3–1 Chapter 3. FUNCTIONAL AND PHYSICAL DESCRIPTIONS 3.1 Dimensional Envelope All dimensions are in English units (centimeters are in parentheses). 3

CDM-710 Satellite Modulator Revision 2 Functional and Physical Description MN/CDM710.IOM 3–2 3.1.2 Ku-Band LNA

4–1 Chapter 4. SPECIFICATIONS 4.1 Summary of Specifications Frequency CLNA 3.4 to 4.2 GHz 3.625 to 4.2 GHz 4.5 to 4.8 GHz KLNA 10.95 to 12.75 GHz N

LNA Low Noise Amplifier Series Revision 0 Specifications MN/LNAS.IOM 4–2 Notes: __________________________________________________________________

METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281

2114 WEST 7TH STREET TEMPE ARIZONA 85281 USA 480 • 333 • 2200 PHONE 480 • 333 • 2161 FAX

ER-LNAS-EA0 THIS DOCUMENT IS NOT SUBJECT TO REVISION/UPDATE! PLM CO C-0024188 Page 1 of 2 Errata A Comtech EF Data Documentation Update Subject:

ErrataAforMN/LNAS.IOMRev0 ReviseLNAConnPinoutTable,OverTempSpecificationER-LNAS-EA0 THIS DOCUMENT IS NOT SUBJECT TO REVISION/UPDATE!

i LNA Low Noise Amplifier Series Installation and Operation Manual Part Number MN/LNAS.IOM Revision 0 December 14, 2005 Copyright © C

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM iiCustomer Service Contact the Comtech EF Data Customer Support Department for: •

iii Table of Contents CHAPTER 1. INTRODUCTION ...1–1 1.1

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM ivFigures Figure 1-1. LNA Low Noise Amplifier Series...

LNA Low Noise Amplifier Series Revision 0 Preface MN/LNAS.IOM vPreface About this Manual This manual provides installation and operation informati
